16mm 200m Underground Cable Push Pull Rods Fiberglass Duct Rodder

Fiber glass rod inner: Extruded process made of E-fiberglass and high quality resin at high temperature.
Fiber glass rod outer: developed polymer
Assembly: metal frame powder coated; rubber wheels assembly for easy transportation; Guide rollers for rotary coupling; parking brake for the flexible rod control.
Copper wire inside is optional, which is for tracing easily or other professional usage.
Rolling bearing cage for mobility is strong and easy to use.
Feed device allows rod in and out smoothly

16mm 200m Underground Cable Push Pull Rods Fiberglass Duct Rodder

Product Description

Specification	Rod Diameter (mm)	10mm
	Rod Length (m)	300m
	Frame Spec. (mm)	1300x450x1330
Material	Fiber glass rod inner	Extruded by fiber glass and high strength resin at high temperature
	Fiber glass rod outer	High Density polyethylene coating
	Metal Frame	Steel with high-temperature sprayed plastic or hot dip galvanized
Physical Property	Fiber glass content	75-80%
	Density	> 1.9gr/cm3
	Working environment	-40 to +80
	Max. Pulling strength	4000N +/-5%
	Consistency of rod	137gr/m
	Flexural Modulus	> 46.500Mpa
	Elongation at break	2.5-3%
	Min Bending Radius	388mm
